Tako Images: Built-In Image Service for Self-Hosted Apps

Images are sneaky infrastructure.

Your app starts with a few uploads in public/, object storage, or a CDN bucket. Then someone wants avatars cropped square, gallery photos capped at a sensible width, optional AVIF for image-heavy pages, private message attachments, and cache headers that do not accidentally make a user’s photo reusable in the wrong place. Suddenly “show this image” has become a second platform.

Tako now ships that image service in the app boundary you already own. Keep originals wherever your app keeps images; server-side TypeScript can call createImageUrl() from tako.sh/server, hand the signed path to the browser, and let tako-server verify, resize, encode, and cache the response under /_tako/image/v1/.... Storage stays yours. Transformation and policy move into Tako. No separate optimizer service. No query-string soup.

One helper signs the contract

The smallest version is deliberately boring:

import { createImageUrl } from "tako.sh/server";

const photo = createImageUrl("/photos/p_123.jpg");

That signs a private WebP URL with maximum width 1200, quality 75, a 7-day expiration, and 7-day browser-only caching. The return value is a path on your own app:

/_tako/image/v1/<payload>.<signature>

The browser never sees the signing secret. Your server code receives the app-scoped image secret through Tako’s fd 3 bootstrap envelope, the SDK signs a compact payload, and the proxy verifies the signature before it fetches or decodes any image bytes. If someone tampers with width, source, quality, expiration, format, or cache policy, the signature stops matching.

That is the first design choice: URLs are private by default. Use the default for user-specific images, message attachments, account photos, and anything where a shared cache should not keep a copy.

const avatar = createImageUrl(`/avatars/${user.id}.png`, {
  width: 256,
  height: 256,
  crop: "smart",
});

const messagePhoto = createImageUrl(`/messages/${message.id}/photo.jpg`, {
  width: 1200,
  height: 800,
  fit: "cover",
  crop: "smart",
  browserCacheMaxAgeSeconds: 2_592_000,
});

Private responses use Cache-Control: private, so the browser can reuse the result, but shared caches must not. If you do have a non-user-specific asset that should be stable and publicly cacheable, say that explicitly:

const hero = createImageUrl("/assets/home-hero.jpg", {
  width: 1200,
  quality: 80,
  public: true,
});

Public image URLs have no expiration and use long immutable public cache headers. Tako makes that an option, not the default, because “this can be shared forever” is a real product decision.

Resize, crop, and format without a side service

Tako’s optimizer is intentionally narrow. It accepts local paths or remote http/https sources, rejects private and local remote hosts, and transforms JPEG, PNG, GIF, WebP, and AVIF sources by file signature. Animated GIF and WebP sources keep animation for optimized resize and crop URLs, and animated AVIF requests fall back to WebP. It emits WebP by default, or AVIF for still images when you opt into the smaller, slower-to-encode format:

const avif = createImageUrl("/avatars/u_123.png", {
  width: 256,
  format: "avif",
});

You do not pass format: "webp" because WebP is the default. Omitting format keeps the payload smaller and leaves the default obvious.

Width-only requests preserve aspect ratio and never upscale. If the original image is 800px wide and you request 1200, the output stays 800px. Fixed boxes require both width and height, then choose cover or contain:

const square = createImageUrl("/uploads/profile.jpg", {
  width: 384,
  height: 384,
  fit: "cover",
  crop: "smart",
});

const product = createImageUrl("/catalog/backpack.png", {
  width: 640,
  height: 640,
  fit: "contain",
});

cover fills as much of the box as possible, then crops overflow. crop: "smart" uses libvips attention cropping, which is useful for thumbnails where the interesting part should survive. contain fits inside the box without cropping and rejects crop, because there is nothing to crop.

The useful shape is easier to scan as a table:

The server side uses libvips for resize, crop, and encode work, and strips metadata from transformed output. Server installs include the host libvips runtime, so this is part of the same tako-server surface that already handles routing, TLS, deploys, and static assets.

Why this belongs in Tako

Image optimization sits in the same awkward place as secrets, WebSocket channels, and workflows: too app-specific to be pure infrastructure, too operational to copy into every route handler. The app knows which source image to show, whether it is private, and which crop makes sense. The platform should own signature verification, SSRF protection, byte limits, resize math, cache headers, and the actual image transform.

That split is why createImageUrl() is a small server-only SDK helper instead of a framework component. You can call it from a Hono handler, a TanStack Start server function, a Next.js server component, or plain fetch-handler code. The browser only gets a path. The proxy does the heavy work after the request matches your route, alongside the other reserved /_tako/* endpoints described in How Tako Works.

It also keeps deployment simple. If you can deploy the app with tako deploy, the optimizer comes with it. Sources in public/ are served locally when present; other local paths can be fetched from the matched app backend. Remote image sources are allowed only through the signed URL contract, with unsupported schemes, userinfo, fragments, local/private hosts, local/private DNS results, recursive optimizer URLs, and redirects rejected before transform work happens.

That is the difference from handing raw storage URLs straight to the browser. A CDN can store bytes. Tako can enforce your app’s own policy because the URL was minted by your app, signed with your app’s secret, and served by your app’s platform boundary.

The shape we wanted

The image optimizer is not trying to be a giant media pipeline. It is the 80% path most self-hosted apps need:

That makes images feel like the rest of Tako: your code declares intent, and the platform takes the sharp edges. Read the full config and routing model in tako.toml and deployment docs, or jump into the Tako repo if you want to see the signed payload contract in code.
